Bias power supply main models:


Type

Bias-80k

Bias-300k

Pulse voltage range

50~1000V

50~1000V

Pulse peak current

50A

50A

Output power max

15kW

30kW

Pulse frequency range

1~80kHz

10~300kHz

Pulse width range

0.5~950uS

0.5~95uS

Module synchronization

optical fiber


optical fiber


Waveform interface

optical fiber


optical fiber


Communication

BNC voltage/current


BNC voltage/current


Interface

RS485

RS485/CAN/Profibus/Profinet/TCPIP/EarthCAT  customized


Application

Bias voltage synchronization, which can synchronize the production process with P3E and HiPIMS, and has three synchronization methods.


Bias voltage synchronization, which can synchronize the production process with P3E and HiPIMS, and has three synchronization methods.




Product Advantages:

超强稳定专业的驱动模块
Super stable and professional drive module
高密度集成电路模块
High Density Integrated Circuit Module
高品质原材料
High-quality raw materials
专业的结构设计
Professional structural design
自制传感器
Homemade sensor
丰富的测试设备
Perfect testing process
高端的测试设备
Variety of test equipment
完善的检测流程
High-end test equipment


Customized power supply product details:

Examples of High Power Pulse Power and High Voltage Pulse Power Products
